WinKeyer Rev A/B 3.01.02 Update File:
IC:SMT - WKUSB Rev A/B with FTDI USB I/F
WinKeyer Rev A/B 3.01.02 Update File:
IC:DIP - WKUSB Rev A/B with FTDI USB I/F
WKUSB Rev A Mini 3.01.02 Update File:
IC:MINI - WK Mini Rev A with FTDI USB I/F
Here is the WKUSB Manual with WK 3.1 updates

Here is the WK3 Datasheet with WK 3.1 updates

Here is the WKmini Datasheet with WK 3.1 updates


In case of difficulties, fall back programming files for WKUSB Rev A/B and WKmini Rev A are listed below in case you want to revert back to version 3.00.10:



WK3demo_42_setup.exe Version 4.2:
WK3tools_53_setup.exe Version 5.3:
WinKeyer Rev A/B 3.00.10 Update File:
IC:SMT - WKUSB Rev A/B with FTDI USB I/F
WinKeyer Rev A/B 3.00.10 Update File:
IC:DIP - WKUSB Rev A/B with FTDI USB I/F
WKUSB Rev A Mini 3.00.10 Update File:
IC:MINI - WK Mini Rev A with FTDI USB I/F
WinKeyer Version 3.1 Upgrade Files

This is the repository for WK 3.1 Upgrade Files. They are compatible with any K1EL WinKeyer that has a WK 3 IC except for WK3serial and WKlite. There are several different versions, please verify that you are using the correct image file for the keyer you have. The .03 files are special versions for keyers that use the CH340 USB interface.

WK3tools and WK3demo have been updated to support WinKeyer 3.1 links to be these can be found below. WK3demo will not fully recognize an older IC version so you will need to upgrade your keyer to 3.1first.

To determine the version of keyer you have, run WK3tools 5.3, set the com port, click Test WK and the version will be displayed: IC:DIP, IC:SMT, IC:AF or IC:MINI.  Select the appropriate image from the list below. Instructions for upgrading can be found in the WK3TOOLS Guidebook on Page 8, PLEASE BE SURE TO READ THIS !! When you use WK3tools 5.3 with an older WK3 version, only a few options are enabled. Once you do the upgrade, everything will be enabled.

DO NOT USE ANY OF THESE FILES FOR K45 or WKnano UPGRADE !
THEY ARE NOT COMPATIBLE WITH THE WK3-IC IN EITHER PRODUCT
NOT FOR WKnano, K45A, or K45B !!!!
or WK2serial or WK3serial


Home



Keyer Kits



ICs



Radios



PIC Tools



Software



Videos



Deals



WKUSB Rev C 3.01.03 Update File:
IC:SMT - WKUSB Rev C with CH340 USB I/F
WKUSB-AF Rev A 3.01.03 Update File:
IC:AF - WKUSB-AF with CH340 USB I/F
WK Mini Rev B 3.01.03 Update File:
IC:MINI - WK MINI Rev B with CH340 USB I/F
WK 3.0 based keyers MUST use the WK3tools 4.3 App !!
