K1EL Systems LLC
The K44 is the Swiss Army knife of CW keyers. A CW keyboard interface, CW reader, iambic paddle keyer, backlit LCD display, and optically isolated keying outputs are all presented in one compact box. In addition, the K44 will operate many different modes including QRSS, HSCW, and conventional CW up to 140 WPM. We sell the K44 assembled, tested, and ready to go. A power source from 9 to 12 VDC is required, the K44 has a 2.1mm power jack with center plus. Please review the cable recommendations link for K44 cabling info. We do not include a keyboard with the K44, almost any PS/2 keyboard will work fine, the User Manual provides suggestions on this.

The on board CW reader accepts audio from a receiver, then filters, demodulates, and decodes CW characters which are then displayed on the LCD. An LED array is used to tune in CW stations quickly and accurately. The K44 CWR is a new design featuring much improved copy and faster reader lock than the original K42 CWR.


K44 Features
K44 CW Keyer & Reader w/Keyboard I/F













What changed from K42 to K44 ?

K44 Documentation
K44 User Guide rev A.3
Manual de Uso K44 - Spanish translation by EA7AZ

K44 CWR Reader Tips and Tricks

NEW ! K44 Audio Splitter kit

K44 Assembly Manual rev A.0

CW Reader Specifications



Home



Keyer Kits



ICs



Radios



PIC Tools



Software



Videos



Deals



K44 Assembled
$159.00 USD
K44 Cable Options
Click for more pictures
We are not able to ship K44s to EU, Please order from Kanga UK who is our authorized distributor.
Information

Contact Us
Documentation
Frequently Asked Questions
Privacy Policy
About Us


Customer Service

Terms and Conditions
Return & Repair Policy
Ordering Info
Shipping Methods
Connections

Copyright 2000-2019 - K1EL Systems LLC
Twitter: @k1elsystems
News: K1EL Systems Blog
Help: K1EL on Groups.io


Replaced by the K45
